Eaton Wiring Devices 1709-BOX Electrical Plug, Straight Blade, 1/4 to 39/64 in, 2-Pole, 15 A, 125 V, NEMA: NEMA 5-15 PACK OF: 10

$60.00 $75.00 Save $15

Eaton SKU: 4181780 Barcode: 32664480706

15 Day
Return Policy

Ships Fast
in 24 hours

Reduced
Emissions

In stock!

Meets all UL 498 requirements. Solid brass straight plug blades. Combination slot/Phillips head mounting and terminal screws. Temperature rating of -20 to 60 deg C. 15 A, 125 V. 1/4 to 39/64 in cord diameter. UL listed, CSA Certified. NEMA 5-15P.

Features

  • Solid brass plug blades are firmly embedded in body
  • Thermoplastic rubber plugs and connectors maintain flexibility in extremely low temperatures
  • Terminals in individual chambers to positively insulate conductors
  • Terminal screw clamps are designed to contain wire and prevent binding
  • Terminal screws backed out ready for wiring
  • Combination Slotted/Phillips head mounting and terminal screws ease installation with power screwdrivers

Specifications

Cable/Wire Size 1/4 to 39/64 in
Color Black
Connection Type Screw
Current Rating 15 A
Dimensions 2 in L x 1.54 in W
Grounding Type Grounded
Material Thermoplastic
Mounting Type Screw
NEMA Configuration NEMA 5-15
Number of Poles 2
Number of Wires 3
Operating Temperature -20 to 60 deg C
Type Straight Blade
Voltage Rating 125 V
